“Dolphin” Torque Multipliers are precision Gear units designed for multiplication of input Torque multipliers are recommended to be used where very high Torque are required to minimise input effort. We offer high quality hand torque multipliers that are portable in design and offer accurate results. Torque multipliers provide extra mechanical advantage that is needed to tighten or loosen nuts and bolts located at inaccessible positions. This is a versatile manual tool, which increases the torque capacity of torque wrenches & hand ratchets.
MODEL NO. | TORQUE CAPACITY | BOLT CAPACITY | FACTOR | FEMALE INPUT SQ. IN | MALE OUTPUT SQ. IN | RECMD. TORQUE WRENCH | APPROX.WEIGHT WITH REACTION PLATE (Kg) |
||
Lb.ft. | Kgm | In. | mm | ||||||
DTM-1 | 1250 | 170 | 1.1/8 | 28 | 5 | 1/2 | 3/4 | DTR 330 | 4.5 |
DTM-2 | 1250 | 170 | 1.1/8 | 28 | 5 | 3/4 | 1 | DTR 330 | 5.0 |
DTM-2/25 | 1250 | 170 | 1.1/8 | 28 | 25 | 1/2 | 1 | DTR 135 | 7.0 |
DTM-5 | 2000 | 275 | 1.3/8 | 35 | 5 | 3/4 | 1 | DTR 560 | 8.0 |
DTM-5/25 | 2000 | 275 | 1.3/8 | 35 | 25 | 1/2 | 1 | DTR 135 | 11.0 |
DTM-6 | 2500 | 345 | 1.1/2 | 38 | 5 | 3/4 | 1.1/2 | DTR 810 | 8.5 |
DTM-6/25 | 2500 | 345 | 1.1/2 | 38 | 25 | 1/2 | 1.1/2 | DTR 135 | 11.5 |
DTM-7 | 4500 | 622 | 2.1/2 | 62 | 5 | 3/4 | 1.1/2 | DTR 225 | 15.5 |
DTM-7/25 | 4500 | 622 | 2.1/2 | 62 | 25 | 3/4 | 1.1/2 | DTR 330 | 19.5 |
DTM-7/25SD | 4500 | 622 | 2.1/2 | 62 | 25 | 3/4 | 1.1/2 | DTR 330 | 20.0 |
DTM-125 | 4500 | 622 | 2.1/2 | 62 | 125 | 1/2 | 1.1/2 | DTR 68 | 25.0 |
DTM-7/125SD | 4500 | 622 | 2.1/2 | 62 | 125 | 1/2 | 1.1/2 | DTR 68 | 26.0 |
DTM-9/25 | 7000 | 968 | 3.0 | 75 | 25 | 3/4 | 1.1/2 | DTR 810 | 25.0 |
DTM-9/125 | 7000 | 968 | 3.0 | 75 | 125 | 1/2 | 1.1/2 | DTR 135 | 32.0 |
DTM-1 | 1250 | 170 | 1.1/8 | 28 | 5 | 1/2 | 3/4 | DTR 330 | 4.5 |
